    • main product photo
    Cutters with shank

    Router cutter Diamaster PRO3, Z 3+3, Nesting

    As low as £515.40 Regular Price £50,000.00
    To Purchase Selection
    Poly-cristalline diamond (PKD)
    Poly-cristalline diamond (PKD)
    Grooving, sizing
    Grooving, sizing
    Mechanical feed
    Mechanical feed
    Special body alloy
    Special body alloy
    Tipped tool
    Tipped tool

    Information

    Information
    Application: Router cutter for sizing and grooving (Nesting) at high feed speeds. For tear-free cut edges on both sides of the workpiece.
    Machine: Stationary routers with/without CNC control, machining centres, milling machines with spindles to mount shank tools.
    Workpiece material:

    Chipboard and fibre materials (MDF, HDF etc.), uncoated, plastic coated, veneered etc., laminated veneer lumber (plywood, multiplex plywood etc.).
    Technical information:

    Spiral cutting edge arrangement with alternate shear angle and real - Z 3 over the complete cutting length, with DP plunging tip. Resharpenable up to 3 times with normal wear. Tool body made from high-tensile material. Important to follow the application data parameters.
    Downloads
    Product information
    to product website
    Tool Selection
    i
    Id D
    mm     		GL
    mm     		NL
    mm     		lpos.
    mm     		S
    mm     		ap min
    mm     		DRI
    191030 Router cutter Diamaster PRO
    DP/D12/NL19/GL65/S12x42/RH/Z3+3
    D: 12 mm
    GL: 65 mm
    NL: 19 mm
    lpos.: 7.5 mm
    S: 12x42 mm
    ap min: 9 mm
    DRI: RH
    £515.40
    from 1 Qty £515.40
    In Stock
    *stock levels may be subject to change
    191031 Router cutter Diamaster PRO
    DP/D12/NL24/S12/GL70/RH
    D: 12 mm
    GL: 70 mm
    NL: 24 mm
    lpos.: 7.5 mm
    S: 12x42 mm
    ap min: 9 mm
    DRI: RH
    £609.92
    from 1 Qty £609.92
    In Stock
    *stock levels may be subject to change
    191032 Router cutter Diamaster PRO
    DP/D12/NL28/S12/GL75/RH
    D: 12 mm
    GL: 75 mm
    NL: 28 mm
    lpos.: 7.5 mm
    S: 12x42 mm
    ap min: 9 mm
    DRI: RH
    £687.70
    from 1 Qty £687.70
    In Stock
    *stock levels may be subject to change
    • 191030 Router cutter Diamaster PRO
      DP/D12/NL19/GL65/S12x42/RH/Z3+3
      D: 12 mm
      GL: 65 mm
      NL: 19 mm
      lpos.: 7.5 mm
      S: 12x42 mm
      ap min: 9 mm
      DRI: RH
      £515.40
      from 1 Qty £515.40
      In Stock
      *stock levels may be subject to change
    • 191031 Router cutter Diamaster PRO
      DP/D12/NL24/S12/GL70/RH
      D: 12 mm
      GL: 70 mm
      NL: 24 mm
      lpos.: 7.5 mm
      S: 12x42 mm
      ap min: 9 mm
      DRI: RH
      £609.92
      from 1 Qty £609.92
      In Stock
      *stock levels may be subject to change
    • 191032 Router cutter Diamaster PRO
      DP/D12/NL28/S12/GL75/RH
      D: 12 mm
      GL: 75 mm
      NL: 28 mm
      lpos.: 7.5 mm
      S: 12x42 mm
      ap min: 9 mm
      DRI: RH
      £687.70
      from 1 Qty £687.70
      In Stock
      *stock levels may be subject to change

    RPM: nmax = 24000 min-1
