    • main product photo
    Drills

    Hinge drill HW-solid, shank 10 mm, GL 70 mm, short centre point, Z 3 / V 3

    As low as £57.00 Regular Price £50,000.00
    To Purchase Selection
    Tungsten carbide
    Tungsten carbide
    Drilling blind holes
    Drilling blind holes
    Manual feed
    Manual feed
    Solid metal tool
    Solid metal tool

    Information

    Information
    Application:

    For drilling hinge holes, particularly in furniture construction, with increased lifetime and high-quality edge. Design for higher feed speed in comparison to boring bits with Z 2 / V 2.
    Machine: Point-to-point drilling machines, through feed drilling machines, CNC machining centres, hinge boring machines, multi spindle units.
    Workpiece material:

    Softwood and hardwood, chipboard and fibre materials (MDF, HDF etc.), uncoated, plastic coated, veneered etc., laminated veneer lumber (plywood, multiplex plywood etc.).
    Technical information:

    Round spur geometry for increased edge quality. Solid tungsten carbide design. High wear resistant tungsten carbide grade. Tear-free edges in panels with glued plastic edgebanders when used on main spindle, boring units as well as drilling machines.
    Downloads
    Product information
    to product website
    Tool Selection
    i
    Id D
    mm     		GL
    mm     		L
    mm     		S
    mm     		DRI
    37272 Hinge boring bit
    HW/D25/S10x26/GL70/LL
    D: 25 mm
    GL: 70 mm
    L: 68 mm
    S: 10x26 mm
    DRI: LH
    £58.10
    from 1 Qty £58.10
    In Stock
    *stock levels may be subject to change
    37273 Hinge boring bit
    HW/D25/S10x26/GL70/RL
    D: 25 mm
    GL: 70 mm
    L: 68 mm
    S: 10x26 mm
    DRI: RH
    £57.00
    from 1 Qty £57.00
    In Stock
    *stock levels may be subject to change
    37280 Hinge boring bit
    HW/D35/S10x26/GL70/LL
    D: 35 mm
    GL: 70 mm
    L: 68 mm
    S: 10x26 mm
    DRI: LH
    £61.75
    from 1 Qty £61.75
    In Stock
    *stock levels may be subject to change
    37281 Hinge boring bit
    HW/D35/S10x26/GL70/RL
    D: 35 mm
    GL: 70 mm
    L: 68 mm
    S: 10x26 mm
    DRI: RH
    £64.00
    from 1 Qty £64.00
    In Stock
    *stock levels may be subject to change
    • 37272 Hinge boring bit
      HW/D25/S10x26/GL70/LL
      D: 25 mm
      GL: 70 mm
      L: 68 mm
      S: 10x26 mm
      DRI: LH
      £58.10
      from 1 Qty £58.10
      In Stock
      *stock levels may be subject to change
    • 37273 Hinge boring bit
      HW/D25/S10x26/GL70/RL
      D: 25 mm
      GL: 70 mm
      L: 68 mm
      S: 10x26 mm
      DRI: RH
      £57.00
      from 1 Qty £57.00
      In Stock
      *stock levels may be subject to change
    • 37280 Hinge boring bit
      HW/D35/S10x26/GL70/LL
      D: 35 mm
      GL: 70 mm
      L: 68 mm
      S: 10x26 mm
      DRI: LH
      £61.75
      from 1 Qty £61.75
      In Stock
      *stock levels may be subject to change
    • 37281 Hinge boring bit
      HW/D35/S10x26/GL70/RL
      D: 35 mm
      GL: 70 mm
      L: 68 mm
      S: 10x26 mm
      DRI: RH
      £64.00
      from 1 Qty £64.00
      In Stock
      *stock levels may be subject to change

    RPM: n = 3000 - 9000 min-1

    Spare parts:
    Id BEZ ABM
    5802 Allen screw
    M5x10
    		BEZ: Allen screw ABM: M5x10
    £1.66
    from 1 Qty £1.66
    In Stock
    *stock levels may be subject to change
    9157 Length adjustment screw Torx® 20
    M5x17
    		BEZ: Length adjustment screw Torx® 20 ABM: M5x17
    £1.95
    from 1 Qty £1.95
    In Stock
    *stock levels may be subject to change
    • 5802 Allen screw
      M5x10
      BEZ: Allen screw
      ABM: M5x10
      £1.66
      from 1 Qty £1.66
      In Stock
      *stock levels may be subject to change
    • 9157 Length adjustment screw Torx® 20
      M5x17
      BEZ: Length adjustment screw Torx® 20
      ABM: M5x17
      £1.95
      from 1 Qty £1.95
      In Stock
      *stock levels may be subject to change

    Leitz UK have many more products available over those you can see on the online shop.

    Please contact our Customer Service Team for further details.
