    • main product photo
    Cutters with shank

    HeliPlan planing cutter

    As low as £247.92 Regular Price £50,000.00
    To Purchase Selection
    Tungsten carbide
    Tungsten carbide
    Rebating
    Rebating
    Mechanical feed
    Mechanical feed
    Mechanical knife clamping, reversible
    Mechanical knife clamping, reversible

    Information

    Information
    Application:

    For surface planing of large workpieces and for cutting wide rebates in one operation.
    Machine: Stationary routers with/without CNC control, machining centres.
    Workpiece material: Softwood and hardwood, chipboard and fibre materials (MDF, HDF etc.), uncoated, plastic coated, veneered etc., laminated veneer lumber (plywood, multiplex plywood etc.), duromers, plastomers, solid surface material (Corian, Varicor etc.).
    Technical information:

    Cutting edge with shear angle; reversible and replaceable knives. D 135 and D 180 particularly suitable for planing MDF spoilboards in nesting applications. Excellent cutting result through optimized cutting geometry.
    Downloads
    Product information
    to product website
    Tool Selection
    i
    Id D
    mm     		GL
    mm     		NL
    mm     		S
    mm     		Z
    		 nmax
    min-1     		DRI
    41554 Turnblade planing cutter HeliPlan
    HW/D80/SB12/S20x50/L90/Z3
    D: 80 mm
    GL: 90 mm
    NL: 15 mm
    S: 20x50 mm
    Z: 3
    nmax: 14000 min-1
    DRI: RH
    £256.60
    from 1 Qty £256.60
    In Stock
    *stock levels may be subject to change
    41555 Turnblade planing cutter HeliPlan
    HW/D80/SB12/S25x60/L100/Z3
    D: 80 mm
    GL: 100 mm
    NL: 15 mm
    S: 25x60 mm
    Z: 3
    nmax: 14000 min-1
    DRI: RH
    £247.92
    from 1 Qty £247.92
    In Stock
    *stock levels may be subject to change
    41556 Turnblade planing cutter HeliPlan
    HW/D135/NL12/S25x60/GL90/Z4
    D: 135 mm
    GL: 90 mm
    NL: 15 mm
    S: 25x60 mm
    Z: 4
    nmax: 10000 min-1
    DRI: RH
    £394.60
    from 1 Qty £394.60
    In Stock
    *stock levels may be subject to change
    41557 Turnblade planing cutter HeliPlan
    HW/D180/NL12/S25x55/L90/Z5
    D: 180 mm
    GL: 90 mm
    NL: 15 mm
    S: 25x60 mm
    Z: 5
    nmax: 8400 min-1
    DRI: RH
    £656.90
    from 1 Qty £656.90
    In Stock
    *stock levels may be subject to change
    • 41554 Turnblade planing cutter HeliPlan
      HW/D80/SB12/S20x50/L90/Z3
      D: 80 mm
      GL: 90 mm
      NL: 15 mm
      S: 20x50 mm
      Z: 3
      nmax: 14000 min-1
      DRI: RH
      £256.60
      from 1 Qty £256.60
      In Stock
      *stock levels may be subject to change
    • 41555 Turnblade planing cutter HeliPlan
      HW/D80/SB12/S25x60/L100/Z3
      D: 80 mm
      GL: 100 mm
      NL: 15 mm
      S: 25x60 mm
      Z: 3
      nmax: 14000 min-1
      DRI: RH
      £247.92
      from 1 Qty £247.92
      In Stock
      *stock levels may be subject to change
    • 41556 Turnblade planing cutter HeliPlan
      HW/D135/NL12/S25x60/GL90/Z4
      D: 135 mm
      GL: 90 mm
      NL: 15 mm
      S: 25x60 mm
      Z: 4
      nmax: 10000 min-1
      DRI: RH
      £394.60
      from 1 Qty £394.60
      In Stock
      *stock levels may be subject to change
    • 41557 Turnblade planing cutter HeliPlan
      HW/D180/NL12/S25x55/L90/Z5
      D: 180 mm
      GL: 90 mm
      NL: 15 mm
      S: 25x60 mm
      Z: 5
      nmax: 8400 min-1
      DRI: RH
      £656.90
      from 1 Qty £656.90
      In Stock
      *stock levels may be subject to change

    Spare knives:
    Id BEZ ABM
    9535 Turnblade knife
    HW:15x15x2.5
    		BEZ: Turnblade knife ABM: HW:15x15x2.5
    £5.15
    from 1 Qty £5.15
    In Stock
    *stock levels may be subject to change
    • 9535 Turnblade knife
      HW:15x15x2.5
      BEZ: Turnblade knife
      ABM: HW:15x15x2.5
      £5.15
      from 1 Qty £5.15
      In Stock
      *stock levels may be subject to change

    Spare parts:
    Id BEZ ABM
    114049 Countersink screw, Torx® 20
    M5x9
    		BEZ: Countersink screw, Torx® 20 ABM: M5x9
    £4.48
    from 1 Qty £4.48
    In Stock
    *stock levels may be subject to change
    • 114049 Countersink screw, Torx® 20
      M5x9
      BEZ: Countersink screw, Torx® 20
      ABM: M5x9
      £4.48
      from 1 Qty £4.48
      In Stock
      *stock levels may be subject to change
