Spindle without twist protection
Hydro clamping system - closed
Hydro-Duo (bi-directional) clamping
Information
| Application: | Hydro-Duo clamping sleeve for high precision clamping and flexible positioning of saws, cutters and hoggers on spindles without using spacers or spindle nuts. |
|---|---|
| Machine: | Multi-blade circular saw machines, four-sided moulders, double-end tenoners etc. |
| Technical information: | Closed hydro clamping system with maintenance free pressure piston mechanism. |
Downloads
Product information
Tool selection
| Id |
d mm |
BO mm |
NLA mm |
NL mm |
L mm |
GL mm |
ND mm |
DB mm |
TK mm |
Stock |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
30572
Hydro-Duo clamping element
100x60/40x69,SPH35 |
d:
60
mm
|
BO:
40
mm
|
NLA:
3/M6/75
mm
|
NL:
35
mm
|
L:
35
mm
|
GL:
69
mm
|
ND:
69
mm
|
DB:
100
mm
|
TK:
75
mm
|
Stock:
1
Stock:
available from stock
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
30574
Hydro-Duo clamping element
100x60/50x69,SPH35 |
d:
60
mm
|
BO:
50
mm
|
NLA:
3/M6/75
mm
|
NL:
35
mm
|
L:
35
mm
|
GL:
69
mm
|
ND:
69
mm
|
DB:
100
mm
|
TK:
75
mm
|
Stock:
1
Stock:
available from stock
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
30571
Hydro-Duo clamping element
120x90/69.71x70,SPH35 |
d:
90
mm
|
BO:
70
mm
|
NLA:
6/M6/106
mm
|
NL:
35
mm
|
L:
35
mm
|
GL:
70
mm
|
ND:
70
mm
|
DB:
120
mm
|
TK:
106
mm
|
Stock:
Stock:
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
30557
Hydro-Duo clamping element
145x115/100x49.5,SPH14 |
d:
115
mm
|
BO:
100
mm
|
NLA:
6/M6/131
mm
|
NL:
14
mm
|
L:
14
mm
|
GL:
49.5
mm
|
ND:
49,5
mm
|
DB:
145
mm
|
TK:
131
mm
|
Stock:
1
Stock:
available from stock
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
30555
Hydro-Duo clamping element
145x115/100x84,SPH48.5 |
d:
115
mm
|
BO:
100
mm
|
NLA:
6/M6/131
mm
|
NL:
48.5
mm
|
L:
48.5
mm
|
GL:
84
mm
|
ND:
84
mm
|
DB:
145
mm
|
TK:
131
mm
|
Stock:
1
Stock:
available from stock
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
-
30572 Hydro-Duo clamping element
100x60/40x69,SPH35d: 60 mmBO: 40 mmNLA: 3/M6/75 mmNL: 35 mmL: 35 mmGL: 69 mmND: 69 mmDB: 100 mmTK: 75 mmStock: available from stockStock: 1Request Price -
30574 Hydro-Duo clamping element
100x60/50x69,SPH35d: 60 mmBO: 50 mmNLA: 3/M6/75 mmNL: 35 mmL: 35 mmGL: 69 mmND: 69 mmDB: 100 mmTK: 75 mmStock: available from stockStock: 1Request Price -
30571 Hydro-Duo clamping element
120x90/69.71x70,SPH35d: 90 mmBO: 70 mmNLA: 6/M6/106 mmNL: 35 mmL: 35 mmGL: 70 mmND: 70 mmDB: 120 mmTK: 106 mmStock:Stock:Request Price -
30557 Hydro-Duo clamping element
145x115/100x49.5,SPH14d: 115 mmBO: 100 mmNLA: 6/M6/131 mmNL: 14 mmL: 14 mmGL: 49.5 mmND: 49,5 mmDB: 145 mmTK: 131 mmStock: available from stockStock: 1Request Price -
30555 Hydro-Duo clamping element
145x115/100x84,SPH48.5d: 115 mmBO: 100 mmNLA: 6/M6/131 mmNL: 48.5 mmL: 48.5 mmGL: 84 mmND: 84 mmDB: 145 mmTK: 131 mmStock: available from stockStock: 1Request Price
with clamping screws.
Explanation of abbreviations
d
Clamping diameter
BO
Bore diameter / interface
NLA
Pinhole dimensions
NL
Cutting length
L
Length
GL
Total length
ND
Thickness of hub
DB
Diameter of shoulder
TK
Reference diameter
Stock
Stock availability
