Spindle without twist protection
Hydro clamping system - closed
Hydro-Duo (bi-directional) clamping
Information
| Application: | Hydro-Duo clamping sleeve with fine thread and axial piston clamping for stepless adjustment of 2 part tool sets. Additional clamping collar with safety device against twisting. |
|---|---|
| Machine: | Machines with high precision spindles, e.g. moulders, double-end tenoners, edgebanding machines etc. |
| Technical information: | High precision fine thread adjustment with a 0.01 mm scale for fine adjustment of 2 part cuttersets with repeatability. Adjustment range 10 mm. Maintenance free hydro clamping mechanism. |
Downloads
Product information
Tool selection
| Id |
d mm |
BO mm |
BO in |
NL mm |
L mm |
GL mm |
ND mm |
DB mm |
VSB |
TK mm |
Stock |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
31555
Hydro-Duo clamping element
120x80/40x117 |
d:
80
mm
|
BO:
40
mm
|
BO:
in
|
NL:
33.5
mm
|
L:
88
mm
|
GL:
108
mm
|
ND:
108
mm
|
DB:
120
mm
|
VSB:
10
|
TK:
100
mm
|
Stock:
2
Stock:
available at short notice
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
30566
Hydro-Duo clamping element
140x100/50x117 |
d:
100
mm
|
BO:
50
mm
|
BO:
in
|
NL:
60
mm
|
L:
102
mm
|
GL:
117
mm
|
ND:
117
mm
|
DB:
140
mm
|
VSB:
10
|
TK:
120
mm
|
Stock:
2
Stock:
available at short notice
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
31552
Hydro-Duo clamping element
140x100/53,97x117 |
d:
100
mm
|
BO:
53,97
mm
|
BO:
2 1/8″
in
|
NL:
60
mm
|
L:
102
mm
|
GL:
112
mm
|
ND:
117
mm
|
DB:
140
mm
|
VSB:
10
|
TK:
120
mm
|
Stock:
2
Stock:
available at short notice
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
-
31555 Hydro-Duo clamping element
120x80/40x117d: 80 mmBO: 40 mmBO: inNL: 33.5 mmL: 88 mmGL: 108 mmND: 108 mmDB: 120 mmVSB: 10TK: 100 mmStock: available at short noticeStock: 2Request Price -
30566 Hydro-Duo clamping element
140x100/50x117d: 100 mmBO: 50 mmBO: inNL: 60 mmL: 102 mmGL: 117 mmND: 117 mmDB: 140 mmVSB: 10TK: 120 mmStock: available at short noticeStock: 2Request Price -
31552 Hydro-Duo clamping element
140x100/53,97x117d: 100 mmBO: 53,97 mmBO: 2 1/8″ inNL: 60 mmL: 102 mmGL: 112 mmND: 117 mmDB: 140 mmVSB: 10TK: 120 mmStock: available at short noticeStock: 2Request Price
Explanation of abbreviations
d
Clamping diameter
BO
Bore diameter / interface
BO
Bore diameter
NL
Cutting length
L
Length
GL
Total length
ND
Thickness of hub
DB
Diameter of shoulder
VSB
Adjustment range
TK
Reference diameter
Stock
Stock availability
Spare parts:
| Id | BEZ | ABM | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
5452
Allen key
SW 5 |
BEZ: Allen key | ABM: SW 5 |
Request Price
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
-
5452 Allen key
SW 5BEZ: Allen keyABM: SW 5Request Price
