    Clamping systems

    Hydro-Duo-sleeve for HF-spindle 40 with hexagon, for hoggers

    to Tool selection
    Spindle with anti-twist hexagon
    Spindle with anti-twist hexagon
    Hydro clamping system - closed
    Hydro clamping system - closed
    Hydro clamping
    Hydro clamping

    Information

    Information
    Application:

    Hydro clamping sleeve for play-free clamping of hogging/cutting tools on high precision spindle with hexagon safety device against twisting (HF spindle) for high concentricity.
    Machine:

    Machines with high precision spindles, e.g. moulders, double-end tenoners, edgebanding machines etc.
    Technical information:

    Closed hydro clamping system with maintenance free pressure piston mechanism. RPM nmax 12000 min-1.
    Attention: Comply with maximum admissible speed for the mounted tools!
    Downloads
    Product information
    to product website
    Tool selection
    i
    Id d
    mm     		BO
    mm     		NL
    mm     		L
    mm     		GL
    mm     		ND
    mm     		DB
    mm     		TK
    mm     		Stock
    61702 Hydro clamping sleeve
    118x60/40x96,5
    d: 60 mm
    BO: 40 mm
    NL: 18 mm
    L: 18 mm
    GL: 96.5 mm
    ND: 80,3 mm
    DB: 118 mm
    TK: 100 mm
    Stock: 1
    Stock: available from stock
    61703 Hydro clamping element, HF motor
    110x80/40x98,5
    d: 80 mm
    BO: 40 mm
    NL: 18 mm
    L: 18 mm
    GL: 96.5 mm
    ND: 80,3 mm
    DB: 118 mm
    TK: 100 mm
    Stock: 1
    Stock: available from stock
    • 61702 Hydro clamping sleeve
      118x60/40x96,5
      d: 60 mm
      BO: 40 mm
      NL: 18 mm
      L: 18 mm
      GL: 96.5 mm
      ND: 80,3 mm
      DB: 118 mm
      TK: 100 mm
      Stock: available from stock
      Stock: 1
      Request Price
    • 61703 Hydro clamping element, HF motor
      110x80/40x98,5
      d: 80 mm
      BO: 40 mm
      NL: 18 mm
      L: 18 mm
      GL: 96.5 mm
      ND: 80,3 mm
      DB: 118 mm
      TK: 100 mm
      Stock: available from stock
      Stock: 1
      Request Price

    Spindle fixture consisting of:
    Conical spring washer, clamping screw, hexagon spanner, brace.

    Spare parts:
    Id BEZ ABM
    66473 Securing part
    for HF-spindle HF 40
    		BEZ: Securing part ABM: for HF-spindle HF 40
    Request Price
    • 66473 Securing part
      for HF-spindle HF 40
      BEZ: Securing part
      ABM: for HF-spindle HF 40
