Poly-cristalline diamond (PKD)
Edge trimming
Mechanical feed
Tipped tool
Optimised chip flow
Information
| Application: | For multi-profile cutting with radii and bevelling of edges. Combination of two profiles for automatic profile resetting in the workpiece gap. |
|---|---|
| Machine: | Homag edgebanding machines with cutting unit type FK11, FK20, FK21, FF12, FF32, PF21 with flexTrim cutting head. |
| Workpiece material: | Plastic, softwood, hardwood and veneer edgebander. |
| Technical information: | Two profiles in one tool. DFC design for efficient chip collection. Maximum processing quality through high running accuracy and smooth running. D0 = constant reference diameter, RPM nmax = 18000 min-1. It is recommended to have individual tools changed by the Leitz tool service. |
